Y6-30 boiler centrifugal fan
It is specially designed for boiler using, featured by high efficiency and low noise,the fan is used for ventilation system to transport air without corrosive and adhesive materials. The temperature of the media shall not exceed 250°C.
产数Parameters
| Model(Nº) | Power(kW) | Rotation(r/min) | Volume(m³/h) | Pressure(Pa) |
|---|---|---|---|---|
| 3.5C | 0.75 | 2350 | 655~1192 | 853~727 |
| 5.4C | 3 | 2300 | 2202~3963 | 2157~1833 |
| 6.5C | 5.5 | 2150 | 4263~4945 | 2206~2020 |
| 7.5C | 7.5 | 1900 | 5216~6600 | 2598~2500 |
| 7.5C | 11 | 1900 | 7349~8771 | 2392~2196 |
| 8.6C | 18.5 | 1850 | 9494~14000 | 3226~3040 |
尺寸siz
线图Technical Illustration
