EG axial fan
EG axial fan is a high-efficiency ventilation solution manufactured by POPULA, a professional 100% direct source manufacturer. Designed for the B2B global market, this series provides a factory-direct solution for large-scale air movement, combining energy-saving technology with a robust, rational structure for diverse industrial and commercial applications.
Performance and Utility of the EG axial fan
Sourcing the EG axial fan directly from our manufacturing facility ensures you receive a product optimized for both durability and operational efficiency. The EG series is a preferred choice for professional engineering projects where low-noise performance and high-volume air delivery are critical for maintaining environmental standards.
- Energy-Saving Aerodynamics: Engineered with a focus on electricity saving, the EG series minimizes operational costs while providing powerful and consistent airflow.
- Multi-Industry Versatility: Widely adopted by sectors such as chemical processing, light industry, and civil construction, as well as high-class hotels and commercial complexes.
- Industrial Cooling & Sunstroke Prevention: An ideal device for cooling workshop storage and mining facilities, playing a vital role in sunstroke prevention for large-scale industrial operations.
- Comprehensive Ventilation Solutions: Highly effective for pipeline pressure enhancement, general air supply, and specialized roof ventilation in a variety of industrial settings.
- Rational & Durable Structure: Built with a focus on mechanical stability, the EG axial fan features a rational design that ensures a long service life and reduced maintenance requirements.
Whether you are outfitting a high-end hotel or a heavy-duty industrial workshop, the EG axial fan offers the technical precision and airflow capacity your project demands. Trust POPULA for expert technical support and competitive wholesale pricing on all your professional axial ventilation requirements.
Parameters
| Model(Nº) | Power(kW) | Voltage(V) | Rotation(r/min) | Volume(m³/h) | Pressure(Pa) | Noise dB(A) |
|---|---|---|---|---|---|---|
| EG-2A-2 | 0.18 | 220/380 | 2800 | 600~940 | 80~60 | ≤68 |
| EG-2.5A-4 | 0.18 | 220/380 | 1400 | 790~1460 | 45~24 | ≤58 |
| EG-2.5A-2 | 0.25 | 220/380 | 2800 | 1200~1740 | 168~126 | ≤71 |
| EG-3A-4 | 0.205 | 220/380 | 1400 | 980~1988 | 54~27 | ≤62 |
| EG-3A-2 | 0.3 | 220/380 | 2800 | 2025~3552 | 208~144 | ≤73 |
| EG-3.5A-4 | 0.3 | 220/380 | 1400 | 1989~2980 | 92~25 | ≤63 |
| EG-3.5A-2 | 0.38 | 220/380 | 2800 | 3740~5029 | 271~175 | ≤80 |
| EG-4A-4 | 0.46 | 220/380 | 1400 | 2675~4970 | 150~98 | ≤66 |
| EG-4A-2 | 0.58 | 220/380 | 2800 | 5000~8000 | 352~131 | ≤83 |
| EG-5A-4 | 0.66 | 220/380 | 1400 | 3238~6198 | 159~95 | ≤74 |
| EG-5A-2 | 1.5 | 380 | 2800 | 5191~9346 | 413~218 | ≤85 |
| EG-5A-2 | 2.2 | 380 | 2800 | 7428~11053 | 417~306 | ≤86 |
| EG-5.6A-4 | 1.1 | 380 | 1400 | 6990~10950 | 284~129 | ≤80 |
| EG-6A-4 | 1.8 | 380 | 1420 | 11500~16780 | 288~171 | ≤82 |
| EG-6A-6 | 0.9 | 380 | 910 | 4680~8990 | 160~92 | ≤72 |
| EG-6A-2 | 3 | 380 | 2900 | 10791~15851 | 513~278 | ≤89 |
| EG-6A-2 | 4 | 380 | 2900 | 13259~18409 | 573~374 | ≤91 |
siz
| Model | Motor Power | Ø1 | Ø2 | Ø3 | L | N-Ød | Weight(kg) |
|---|---|---|---|---|---|---|---|
| EG-2A | 0.18kW | 210 | 230 | 260 | 220 | 3-Ø8 | 7 |
| EG-2.5A | 0.25kW | 260 | 280 | 310 | 220 | 3-Ø8 | 8 |
| EG-2.5A | 0.18kW | 260 | 280 | 310 | 220 | 3-Ø8 | 8 |
| EG-3A | 0.3kW | 310 | 330 | 360 | 280 | 3-Ø8 | 12 |
| EG-3A | 0.205kW | 310 | 330 | 360 | 280 | 3-Ø8 | 12 |
| EG-3.5A | 0.38kW | 360 | 380 | 410 | 280 | 4-Ø8 | 16 |
| EG-3.5A | 0.3kW | 360 | 380 | 410 | 280 | 4-Ø8 | 13 |
| EG-4A | 0.58kW | 410 | 430 | 460 | 320 | 4-Ø8 | 18 |
| EG-4A | 0.46kW | 410 | 430 | 460 | 320 | 4-Ø8 | 18 |
| EG-5A | 1.5kW | 510 | 530 | 565 | 380 | 4-Ø8 | 30 |
| EG-5A | 2.2kW | 510 | 530 | 565 | 380 | 4-Ø8 | 37 |
| EG-5A | 0.66kW | 510 | 530 | 565 | 330 | 4-Ø8 | 22 |
| EG-5.6A | 1.1kW | 565 | 585 | 620 | 400 | 4-Ø8 | 38.5 |
| EG-6A | 3kW | 610 | 630 | 665 | 430 | 6-Ø8 | 50 |
| EG-6A | 4kW | 610 | 630 | 665 | 430 | 6-Ø8 | 59 |
| EG-6A | 1.8kW | 610 | 630 | 665 | 430 | 6-Ø8 | 48 |
| EG-6A | 0.9kW | 610 | 630 | 665 | 430 | 6-Ø8 | 44 |
Technical Illustration
